What is BGA Rework?

BGA rework is the process of removing and replacing BGA components on a printed circuit board (PCB). BGA components are integrated circuits that use an array of solder balls to connect to the PCB, rather than the traditional pin-through-hole or surface mount technology. BGA packages offer several advantages, including:

• Higher pin count density
• Improved electrical and thermal performance
• Reduced package size

However, BGA components also present challenges when it comes to rework and repair. Due to the high pin count and small pitch of the solder balls, specialized equipment and expertise are required to successfully remove and replace BGA components without damaging the PCB or surrounding components.

Rocket EMS’s BGA Rework Capabilities

Rocket EMS has invested in state-of-the-art equipment and training to provide customers with reliable and efficient BGA rework services. Their capabilities include:

Equipment

• Semi-automatic BGA rework station with advanced vision system
• Precision placement system with accuracy up to +/- 0.025mm
• Reflow oven with nitrogen atmosphere for optimal solder joint quality
• X-ray inspection system for verifying solder joint integrity

Expertise

• Certified IPC-7711/7721 rework and repair technicians
• Experienced engineers for developing custom rework processes
• Strict adherence to industry standards and best practices

Component Compatibility

Rocket EMS can rework a wide range of BGA component sizes and types, including:

Component Type	Pitch (mm)	Body Size (mm)
Plastic BGA	0.3 – 1.27	2 x 2 to 45 x 45
Ceramic BGA	0.3 – 1.27	6 x 6 to 50 x 50
Flip Chip BGA	0.2 – 0.5	5 x 5 to 40 x 40
Package-on-Package (PoP)	0.3 – 0.65	5 x 5 to 25 x 25

Benefits of BGA Rework

BGA rework offers several benefits for customers with complex PCB assemblies:

Cost Savings

Reworking a BGA component is often more cost-effective than scrapping the entire PCB assembly. By salvaging the PCB and other components, customers can reduce their overall manufacturing costs.

Improved Reliability

Properly reworked BGA components can provide the same level of reliability as the original assembly. Rocket EMS’s advanced equipment and expertise ensure that reworked components meet or exceed the original specifications.

Faster Turnaround Time

BGA rework can be completed much faster than manufacturing a new PCB assembly from scratch. This allows customers to get their products to market faster and minimize downtime in the event of a component failure.

BGA Rework Process

The BGA rework process typically involves the following steps:

1. Inspection: The PCB assembly is inspected to identify the faulty BGA component and assess the overall condition of the board.

2. Component Removal: The faulty BGA component is removed using a combination of heat and mechanical force. Care must be taken to avoid damaging the PCB or surrounding components.

3. Site Preparation: The PCB pads are cleaned and prepared for the new BGA component. This may involve removing any remaining solder, applying new solder paste, or repairing any damaged pads.

4. Component Placement: The new BGA component is precisely placed on the prepared PCB pads using a placement system with high accuracy.

5. Reflow: The PCB assembly is heated in a reflow oven to melt the solder balls and form a reliable connection between the BGA component and the PCB.

6. Inspection: The reworked PCB assembly is inspected using X-ray and other methods to verify the integrity of the solder joints and ensure proper component placement.

Challenges of BGA Rework

While BGA rework offers many benefits, it also presents some challenges that must be addressed:

Thermal Management

BGA components are sensitive to heat, and excessive temperatures can cause damage to the component or the PCB. Proper thermal management is essential during the rework process to ensure that the component and PCB are not exposed to excessive heat.

Moisture Sensitivity

Many BGA components are moisture-sensitive and can be damaged by absorption of moisture from the environment. Proper handling and storage of BGA components is essential to prevent moisture-related failures.

Pad and Trace Damage

The high temperatures and mechanical forces involved in BGA rework can sometimes cause damage to the PCB pads and traces. Careful process control and inspection are necessary to minimize the risk of pad and trace damage.

FAQ

1. Q: What is the maximum BGA component size that Rocket EMS can rework?
   A: Rocket EMS can rework BGA components up to 50 x 50 mm in size.

2. Q: How long does a typical BGA rework process take?
   A: The duration of a BGA rework process depends on the size and complexity of the component and PCB. Typically, a single BGA rework can be completed within 1-2 hours.

3. Q: Can Rocket EMS rework PCBs with multiple BGA components?
   A: Yes, Rocket EMS can rework PCBs with multiple BGA components. The process may take longer depending on the number and complexity of the components.

4. Q: What is the minimum pitch of BGA components that Rocket EMS can rework?
   A: Rocket EMS can rework BGA components with a minimum pitch of 0.2 mm.

5. Q: Does Rocket EMS offer warranty on their BGA rework services?
   A: Yes, Rocket EMS offers a warranty on their BGA rework services. The specific terms of the warranty depend on the customer’s requirements and the complexity of the rework process.

Conclusion

The addition of large BGA rework capability to Rocket EMS’s service offering is a significant development for customers with complex PCB assemblies. With advanced equipment, experienced technicians, and a commitment to quality, Rocket EMS is well-positioned to provide reliable and efficient BGA rework services. By partnering with Rocket EMS, customers can reduce their manufacturing costs, improve product reliability, and accelerate their time to market.
